Silicone Rubber Heating Strip

Name: China Custom Silicone Rubber Heating Strip Manufacturers, Suppliers, Factory - High Quality - Jaye Heater Technology
Brand: Jaye Heater
SKU: 282391151

Products Description The Silicone Rubber Heating Strip is a flexible electric heating element crafted from silicone rubber and fiberglass cloth, integrating nickel-chromium alloy wires or etched foil for efficient heat generation. It excels in rapid, uniform heating with a wide temperature range...

Chat Now

Product Details

Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of silicone rubber heating strip in China, also supports custom service. Welcome to wholesale high quality silicone rubber heating strip at competitive price from our factory.

Products Description

The Silicone Rubber Heating Strip is a flexible electric heating element crafted from silicone rubber and fiberglass cloth, integrating nickel-chromium alloy wires or etched foil for efficient heat generation.

It excels in rapid, uniform heating with a wide temperature range (-60°C to 250°C) and supports voltages from 12V to 480V for versatile customization.

Key advantages include exceptional flexibility for curved surfaces, moisture and chemical resistance, high dielectric strength, and energy efficiency. Its lightweight, thin design (as thin as 1.5mm) allows easy installation on pipes, drums, medical devices, and outdoor equipment, ensuring reliable performance in industrial, aerospace, and automotive applications for freeze protection and process temperature maintenance.

Specification

Main Material	Silicone rubber (V0/V1 grade) reinforced with fiberglass cloth; heating element made of nickel-chromium alloy wire or etched foil
Temperature Rating	Operating range: -60°C to 250°C; Maximum withstand temperature: 250°C - 300°C
Thickness	Standard thickness around 1.5mm (as thin as 0.8mm available); Excellent flexibility for wrapping complex shapes
Voltage	Wide voltage range (e.g., 3V to 660V AC/DC); Power density typically 0.03 to 2.5 W/cm², customizable
3M Tape	Support
Description	Rapid and uniform heating, high thermal efficiency, IP68 waterproof rating, moisture/chemical resistance, and long service life

Features

⦁ 1. Rapid Heating & Extended Service Life

⦁ 2. Excellent Flexibility & High Customizability

⦁ 3. IP68 Rated Waterproof & Eco-Friendly Materials

⦁ 4. Tailored to Specs: Size, Voltage, Wattage, and Shape

⦁ 5. Complimentary Design Service

Application

Industrial Process Heating & Freeze Protection：Ideal for maintaining consistent temperatures and preventing freezing in pipelines, valves, and storage tanks across chemical, food, and manufacturing industries.
Medical & Laboratory Equipment：Used in diagnostic devices, sample heaters, and incubation systems to ensure precise and stable thermal conditions.
Aerospace & Automotive Systems：Provides reliable thermal management for avionics, fuel lines, battery pre-heating, and window defogging applications.
Electronics & Equipment Protection：Safeguards outdoor enclosures, communication cabinets, and sensitive electronics from condensation and low-temperature damage.

Order Guide

To help us provide you with the most accurate quotation and technical solution for your silicone rubber heater, please kindly share the following details with your inquiry.

Quantity	Your required quantity (e.g., prototype samples, small batch, large production run). This helps determine pricing and production scheduling.
Dimensions (Size)	The required Width and Length (in mm or inches). Custom sizes are supported.
Electrical Specifications	Voltage (e.g., 12V, 24V, 110V, 220V, or other AC/DC requirements) and Power or Watt Density (e.g., total Watts or W/cm²).
Configuration & Attach ments	Preferred Wire Length and type for the power leads (standard is often 100cm, customizable). Any need for thermostats, sensors, or specific mounting methods. Drawing or Physical Photos will help us get the exact quotation faster.
