F2000 Type Capillary Thermostat

F2000 type capillary thermostats are mainly used on refrigerator, freezer, showcase, central cooler and seafood pool and the other cooling equipment. Also applicable to dish-washing machine, washing machine, water heater and the other heating equipment.
Chat Now

Product Details

F2000 Type Capillary Thermostat


F2000 type capillary thermostats are mainly used on refrigerator, freezer, showcase, central cooler and seafood pool and the other cooling equipment. Also applicable to dish-washing machine, washing machine, water heater and the other heating equipment.


Technical parameters of the F2000 Capillary thermostat:



1. Temperature range:-30~350℃

2. On-off temperature difference:2~12℃

2. Capillary length: according to customer requirements

3. Warm package size: according to customer requirements

4. Current and voltage: 16A / 250V 50 / 60Hz

5. Sensitivity: 3 ~ 10 ° C

6. Installation size: 28 ± 0.25mm with M4 Screw

7. Body temperature: T150

8. Current strength: 800v / s between two pins

9. Insulation resistance: ≥100MΩ

10. Pin resistance: ≤50MΩ

11. Service life: ≥100,000 times



Features of F2000 Type Capillary thermostats:

1-Refrigerator thermostat

2-Intelligent temperature control meter which is high-performance.

3-Low-cost,good reliability and convenience to use.

4-Can be used to boiler, geo-thermal energy heating equipment, air-condition,electric Heater and electric oven,etc.

5-High accurable and reliable.


Order Guide:



1- Type of Capillary thermostat

2- Temperature range

3- Capillary Length

4- Order Quantity


The various types of liquid expansion temperature controllers (capillary thermostats) developed and produced have temperature control ranges from -35 ° C to 350 ° C with excellent quality, and truly achieves no leakage, no temperature drift, and no contact sintering by Jaye Industry adhering to the principle of customer first and quality first; based on high technology as the means, Our contactless sintering technology has surpassed the quality of similar products and is at the leading level in the world of thermostat industry.
