Electric Oven Regulator Capillary Thermostat
Product Details
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of electric oven regulator capillary thermostat in China, also supports custom service. Welcome to wholesale high quality electric oven regulator capillary thermostat at competitive price from our factory.
Electric Oven Regulator Capillary Thermostat
In order to achieve a better baking effect in the oven, different ingredients need to be set at different temperatures, and the electric oven regulator capillary thermostat can well meet the temperature requirements of the oven. Besides, It is also suited for electric heater,cylinder washer, and so on,as electric-thermal control.
Specifications of Electric Oven Regulator Capillary Thermostat:
1. Control range: 0°C~ 320°C
2. Rate current and rated voltage:16A AC250V & 10A AC400V
3. Life : >100000 Cycle(250V), >45000 Cycle(400V)
4. Current and voltage: 16A/250V 50/60Hz
5. Sensitivity: 10°C
6. Installation size: 28±0.25mm
7. Body temperature: T150
8. Current intensity: 800v/s between two pins
Purchase instructions:
1. The size of the shaft and its initial rotation angle need to be set according to the needs of the customer.
2. The disconnection temperature and its characteristic curve shall be determined by the customer's finished product and temperature control matching test.
3. There are various terminal size specifications and directions, and the length of capillary tube and sheath tube can be selected at will by customers.
4. In order to facilitate the customer to install the thermostat, temperature sensors of different diameters can also be welded in the thermostat.
