Self-Adhesive Foil Heaters
Product Details
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of self-adhesive foil heaters in China, also supports custom service. Welcome to wholesale high quality self-adhesive foil heaters at competitive price from our factory.
Self-Adhesive Foil Heaters with foil backing are being produced to fulfil specific specifications for size, shape, layout, cut-outs, lead wire, and lead termination. The heaters can be provided with dual wattages, dual voltages, built-in temperature control, and sensors.
The Self-Adhesive Foil Heaters can be mechanically affixed with rivets, sheet metal screws, or other mechanical devices, or they can be mounted to a surface using an integrated adhesive. For more demanding applications, a semi-rigid aluminium backing plate delivers structural support.
The Self-Adhesive Foil Heater is composed of a silicone or PVC heating cable, within an aluminium foil coating on both sides, the incorporated adhesive film has a high adhesive content on steel and plastics, allowing in this way simplicity of application and excellent heat exchange, thus ensuring a uniform thermal distribution.
In the refrigeration and air-conditioning sectors it is widely used, but, thanks to the possibility of realizing "tailor-made" elements, it is suitable for many technical solutions.
Specifications
| Resistance Wire Alloy | Alloy- Nichrome 80/ Alloy 875/ Alloy 815/ Nickel 200/ Alloy 30/ Alloy 15/ Alloy 10/ Alloy 5/ Alloy 27 / Alloy 50/Copper/ Stainless Steel/ Customize. |
| Power Range | 50 – 3600 Watt |
| Voltage range | 12,24,110,220 Volt |
| Heating Material | Aluminum Foil sandwiched between two thin sheets of aluminum |
| Max. Continuous Temperature | 200°C |
| Insulation Type | Customized |
| Cold Lead | XLPE/Silicon Insulated 105°C |
| Cold Lead Connection Type | Crimp with Connector |
Our products
Applications
- Maintaining the ideal temperature for food on serving utensils such buffet tables, warming boxes and cabinets, salad bars, chafers, and other similar items.
- To heat equipment such as cylinders, test tube heaters, magnetic stirrers, chambers, containers, pipelines, beakers, and more.
- In order to supply heat for equipment such as incubators, blood warmers, in vitro fertilization heaters, operating tables, befouled warmers, anesthetic heaters, and more.
- To provide radiant heat.
- To prevent condensation on mirrors and battery warming.
- Defense against freezing or maintaining temperature in vertical or horizontal tanks.
- Protection from freezing for plate heat exchangers.
- Electronic or electric control box anti-condensation.
- Refrigerated display cabinets, household items, and medical equipment anti-condensation.
