Oven Upper Heating Element
Product Details
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of oven upper heating element in China, also supports custom service. Welcome to wholesale high quality oven upper heating element at competitive price from our factory.
Oven upper heating element are mainly used in the food processing industry. This kind of heater adopts special production technology and materials, so that the inside of the tube is in a fusion state, the internal vacuum is high, and the transfer from the inside of the tube to the outside is accelerated, thereby improving the service life and thermal efficiency of the tube. This product is highly energy-efficient and stands out among heating products.

Features
1.According to the high-load and high-temp use environment of the equipment, select raw materials with good performance to meet the performance requirements of corrosion resistance and high temp resistance
2.The surface is treated with a special process to prevent the generation of scale
3.The product has undergone 1050℃ thermal reduction heat treatment to ensure the long-term stability of the product

Technical Parameters:
1.Electric tube diameter: ø6.6mm, ø8mm, ,10mm, ø11mm (diameter error: -0.02mm-0.08mm)
2.Tube length: customized as required (error ±1mm)
3.Voltage: 100V-415V customized on demand (deviation within ±5%)
4.Power: customized on demand (deviation within ±5%)
5.Outer tube material: copper, SS304, SS321, SS316L, 310S, INCOLOY840, INCOLOY800
6.Insulating and thermal conductive material: high temperature MGO
7. Wire: Ni80Cr20
8.Leakage current: ≤0.5mA
9.Insulation resistance DC1000V (unheated): ≥1000MΩ
