Injection Molding Barrel Heater
Product Details
Jaye Heater Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of injection molding barrel heater in China, also supports custom service. Welcome to wholesale high quality injection molding barrel heater at competitive price from our factory.
Information
| Material | Copper, SS430, SS304, Cast Aluminum, Cast copper, Cermaic |
| Insulation Material | Imported High-Temperature Mica |
| Resistance Wire | Ni80Cr200 |
| Electrical Property | ≤0.5mA |
| Max. Watt Density | 3 W/cm² |
| Diameter | 25MM |
| Wattage tolerance | +5% -10% |
| Scope of application | Semiconductor manufacturing, Medical appliances, Cable machinery, High temperature heating furnace, Plastic machinery, Mold, Sealing machine, etc |
Working Principle
At present, most injection molding machines in the market still use resistance heating rings, which generate heat based on the thermal effect of current resistance, that is, when the current passes through the conductor, the resistance of the conductor hinders the current, and the current needs to do work to overcome the resistance of the conductor, convert the electric energy into heat energy, and transfer it through contact conduction, Therefore, it is necessary to reliably and closely contact the inner wall of the heating ring with the outer wall of the barrel in order to transfer the heat energy to the barrel.
Advantages/Characteristic
1. Fast heat transfer, uniform heating and stable operation
2. The temperature is not easy to leak out and can save electric energy
3. High power. Ceramic threading method is adopted, and the power is 0.5 ~ 1.5 times higher than that of ordinary ones.
4. Fast heat dissipation, uniform heating, stable performance in high temperature environment, and can be used in 300-600 ℃ environment for a long time
5. The product has a long service life. Due to the slow aging of raw materials at high temperature, the product has a long service life
6. Customizable
[] has the advantages of low price, simple structure and low failure rate due to simple structure. However, its disadvantages are also obvious, because it is contact heat transfer, and the vibration of the injection molding machine in the process of high-speed operation will affect the heating efficiency of the ordinary heating ring, resulting in an increase in energy consumption.
Note
In use, this product will heat and expand, which may make it loose. Please pay attention to frequent inspection, tightening at any time and maintenance in order to prolong its service life.
