Aluminum Casting Band Heater For Vacuum Forming

Aluminum Casting Band Heater For Vacuum Forming

​Jaye offers aluminum casting band heater which contain heating elements casting in, it can bear the load reach to 2.5-4.5W/CM2, working temperature between 400-500 degrees. The aluminum casting heater is uniform heating element with excellent thermal conductivity, ensuring a even temperature on the hot surface.
Chat Now

Product Details

Jaye offers aluminum casting band heater which contain heating elements casting in, it can bear the load reach to 2.5-4.5W/CM2, working temperature between 400-500 degrees. The aluminum casting heater is uniform heating element with excellent thermal conductivity, ensuring a even temperature on the hot surface.



Precautions for the use of cast aluminum electric heaters:

1. The operating voltage must not exceed 10% of the rated value; the relative humidity of the air is not more than 95%, and there is no explosive or corrosive gas.

2. The metal casting heater should be positioned and fixed, the corresponding heating area should be closely attached to the heating body, and empty burning is strictly prohibited. If dust or contaminants are found on the surface, they should be cleaned and reused in time to avoid heat dissipation and shorten the service life.

3. The magnesium oxide powder at the outlet end of the electric heating tube should be protected from the penetration of pollutants and moisture in the place of use to prevent the electric leakage accidents.



Please inform the following parameters when ordering:

1. Voltage Power

2. Inner diameter

3. Height

4. Thickness

5. Length of terminal

6. Whether punch holes or not, and if so, what is the hole diameter
